Durable Multi Head Embroidery Machine , Quilting And Embroidery Machine 1650mm X Area

Durable Multi Head Embroidery Machine , Quilting And Embroidery Machine 1650mm X Area
Durable Multi Head Embroidery Machine , Quilting And Embroidery Machine 1650mm X Area Durable Multi Head Embroidery Machine , Quilting And Embroidery Machine 1650mm X Area

Large Image :  Durable Multi Head Embroidery Machine , Quilting And Embroidery Machine 1650mm X Area

Product Details:
Place of Origin: China
Brand Name: EBD
Certification: CE,SGS,OMA
Model Number: YBD30
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: sea worthy packing
Delivery Time: 30-35days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets/month
Detailed Product Description
N/C/H: 30(double Width) Needle Distance: 67.5mm
X Area: 1650mm Stitch Distance: 1mm-12.7mm
Needle Type: 9#-16# Working Width: 1600mm
Speed: 700R.P.M~900R.P.M Power Supply: AC220/380V,50HZ
Power: 7KW Machine Size: L6700*W1950*H1750(MM)
ITEM NO.: YBD30 Double Width
High Light:

industrial quilting machine

,

computer quilting machine

YBD30 Horizontal Multi Heads Quilting Embroidery Machine-Double Width 67.5mm needle distance



Function:



Quilt and Embroider horizontally alongside the width of fabric. Especially for the horizontal and straight quilting & embroidery designs on the fabric.



Features:

  1. The machine adopted large rotary hook to make neat stitches and with lower noise, and effectively reduced defects such as miss stitches, loose stitches, coarse stitches, etc
  2. Quilt & embroidery completed simutaneously.
  3. The integral steel structure machine frame with higher intensity and stability.
  4. Infrared protection device in all direction make machine operation more safe and reliable.
  5. Function of independent patterns interval quilting, adopting Tensile Motor to keep the fabric smooth at the inlet and outlet fabrics.
  6. Main axis and XY axis are all adopted the Servo Motor.
  7. Function of under and upper thread auto detector, red light displayed on the thread broken position.
  8. Function of edit patterns on the equipment directly, and convenient to read the embroidery format.
  9. Stitches between 1mm-12.7mm adjustable, Sewing Speed: 800-1000/R.P.M.
  10. Safe operation display of quilting and embroidery; Automatic needle run-up and orientation brake system.
  11. Function of pattern patch-up, can efficiently solve the distorted patterns when quilting the thick materials.
  12. Prepared plenty patterns for your choice.



Parameters:



Products: YBD30
N/C/H: 30(double width)
Needle Distance: 67.5mm
X Area: 1650mm
Stitch Distance: 1mm~12.7mm
Needle Type: 9#~16#
Working Width: 1600mm
Speed: 700R.P.M~900R.P.M
Power Supply: AC220/380V,50Hz
Power : 7kw
Machine Size : L6700*W1950*H1750(mm)
Packing Size : L6700*W2300*H1750(mm)
